5.5kW 7HP 2800RPM 3-Phase Electric Motor for Mixers Car Hoists

The YX3 5.5kW 7HP 3-Phase Electric Motor delivers reliable and efficient performance for industrial machinery. Designed for high-speed operation at 2800RPM, this motor features a durable 38mm shaft and operates on 415V power, making it ideal for cement mixers, car hoists, and heavy-duty applications. Built for energy efficiency, consistent power output, and long service life, the YX3 motor is perfect for demanding environments where reliability is key.

Specification:

• Three-phase: 415V /720V
• Speed: 2 Pole (2800rpm)
• Power: 5.5kw/7.5HP
• Maximum Amperage draw: 10.1 Amp
• Shaft size: 38mm
• Light weight
• Aluminium Alloy


Technical Parameters:

• Output (kw): 5.5
• Speed (r/min): 2910
• Amps (A): 10.7
• EFF. (%): 88.6
• P.F. (Cosφ): 0.88
• LRT (RLT): 2.2
• LRA (RLA): 8
• BDT (BDT): 2.3
• Noise (LwdB(A)): 79
• Voltage (V): 415
