53 CFM Industrial Air Dryer Moisture Free Air for Spray Painting CNC & Air Compressors

The 53 CFM Industrial Air Dryer offers essential moisture removal for spray painting, air compressors, and CNC machines. By filtering out harmful moisture from compressed air, it helps prevent equipment damage, ensuring optimal performance. With an airflow capacity of 53 CFM, this air dryer is designed for small to medium industrial applications, offering consistent, moisture-free air for superior results and long-lasting equipment protection.

Design Characteristics

• Unique three-in-one plate type heat exchanger design, compact structure, high heat transfer efficiency. Compare to traditional shell tube heat exchanger, unit heat transfer area enlarges 5 to 10 times.
• High strength aluminum alloy and stainless steel design which is small and light.
• Imported refrigerated valve, compressor is Panasonic.
• Economic auto drain.
• Sensitive and reliable instrument control components

Specification:

• Working Pressure: 0.7-1.3MPa
• Rated Capacity: 1.5 M3/min
• Refrigerant: R134a
• Max Inlet Temperature: 50°C
• Maximum Ambient Temperature: 35°C
• Pressure Dew Point: 3~10°C
• Voltage: 230V / 1Ph / 50Hz
• Dimension: 550*370*704
• Net weight: 60KG
